AutoRebar v2.1 for Autodesk AutoCAD 2013-2021 x64

Description

AutoRebar for Autodesk AutoCAD is the name of an auto-rebar program. With this program, you can quickly do your designs by automating previous repetitive tasks that participate in rebar detailing and are done with regular AutoCAD. You can focus on the concrete part of your design instead of the highly time consuming CAD editing work. With uninterrupted and easy-to-use Autodesk® AutoCAD® software (as well as all vector products), the program adds a new toolbar with special objects for ivory rebars for details of reinforced concrete buildings. There are four types of dynamic objects in this program: Rebars, Marks, Calls and BBS

Features of AutoRebar for Autodesk AutoCAD software:

Draw Rebar objects like polylines, edit their size easily with a double key
Connect all items in AutoRebar graphically and as a result automatically update all connected Marks and Calls
Normal AutoCAD® dimensions link to Marks
Determine the range of a set of rods for the concrete structure to allow AutoRebar to calculate the overall quality in that range
Update the number of bars as soon as the concrete deforms and the dimensions expand
